Key Features
- <ul class="mainfeatureslist">\n <li>8 inputs with 2 outputs of 60 or 120-watts of power</li>\n <li>Independent bass and treble controls for each output channel</li>\n <li>100V and 70V output, or 4?/8?</li>\n</ul>
$960.00
Technical Details
| Form Factor/Type |
Tabletop |
| Number of Channels |
8 Input / 2 Output |
| Power Rating |
4 Ohms / 8 Ohms:
60 W per Channel (1 kHz, 0.5% THD) |
| Load Impedance / Voltage |
4 Ohms (Minimum)
70 V (80 Ohms Minimum)
100 V (160 Ohms Minimum) |
| Frequency Response |
20 Hz to 20 kHz ±2 dB (Low-Z)
80 Hz to 15 kHz ±3 dB (70/100 V) |
| Input Sensitivity |
Mic:
5.5 mVrms
Line:
1.3 Vrms
Stereo RCA:
130 mVrms |
| I/O Impedance |
Mic Input:
400 Ohms
Line Input:
20 Kilohms (Balanced)
RCA Input:
50 Kilohms |
| Insertion Loss |
1 dB Maximum |
| SNR |
> 76 dB (at Rated Power, A-Weighted) |
| THD |
< 0.5% (20 Hz to 20 kHz) |
| Crosstalk |
-70 dB (at Rated Power, Mid Gain, 1 kHz) |
| EQ |
2-Band per Channel:
Bass: ±14 dB at 50 Hz
Treble: ±14 dB at 10 kHz |
| Phantom Power |
27 VDC |
| AC Input Power |
100 VAC, 50 / 60 Hz
120 VAC, 50 / 60 Hz
220 VAC, 50 / 60 Hz
220 to 240 VAC, 50 / 60 Hz |
| Operating Temperature |
32 to 95°F / 0 to 35°C |
| Storage Temperature |
-4 to 185°F / -20 to 85°C |
| Operating Humidity |
0 to 95% (Non-Condensing) |
| Dimensions |
17.0 x 3.5 x 16.3" / 432.0 x 88.0 x 415.0 mm |
| Weight |
25.5 / 11.6 kg |
