Atlas Sound TSDBB22 BlueBridge 2 Input / 2 Output DSP Audio Processor
Atlas Sound TSDBB22 BlueBridge 2 Input / 2 Output DSP Audio Processor is backordered and will ship as soon as it is back in stock.
Need Help? Call Us 800-211-2718
Couldn't load pickup availability
| Input Type | Mic or Line, GUI selectable |
| Configuration | Electronically balanced |
| Gain | -40 to +15 dB in 0.25 dB Steps |
| Polarity | +/-, GUI selectable |
| Input Impedance | >10 kOhms |
| Maximum Input Level | +20 dBu |
| Phantom Power | 48 V, GUI Enabled |
| Output Type | Line |
| Ouput Impedance | 50 ohms |
| Maximum Output Level | +20 dBu |
| Frequency Response | 20 Hz - 20 kHz |
| Dynamic Range | 110 dB Type (unweighted) |
| Common Mode Rejection Ratio | >100 dB (50 Hz - 10 kHz) |
| Distortion | 0.002% (1 kHz @ +4 dBu) |
| Dimensions | 1.5 x 4.0 x 5.2" (3.9 x 10.1 x 13.2 cm) |
| Weight | 13 oz (368 g) |
| External Power Supply | cUL, CE, RoHS, TUV |
DUNS #074303253
IRS W-9 form
Atlas Sound TSDBB22 BlueBridge 2 Input / 2 Output DSP Audio Processor
| Input Type | Mic or Line, GUI selectable |
| Configuration | Electronically balanced |
| Gain | -40 to +15 dB in 0.25 dB Steps |
| Polarity | +/-, GUI selectable |
| Input Impedance | >10 kOhms |
| Maximum Input Level | +20 dBu |
| Phantom Power | 48 V, GUI Enabled |
| Output Type | Line |
| Ouput Impedance | 50 ohms |
| Maximum Output Level | +20 dBu |
| Frequency Response | 20 Hz - 20 kHz |
| Dynamic Range | 110 dB Type (unweighted) |
| Common Mode Rejection Ratio | >100 dB (50 Hz - 10 kHz) |
| Distortion | 0.002% (1 kHz @ +4 dBu) |
| Dimensions | 1.5 x 4.0 x 5.2" (3.9 x 10.1 x 13.2 cm) |
| Weight | 13 oz (368 g) |
| External Power Supply | cUL, CE, RoHS, TUV |
- Drag and Drop architecture
- Mic or Line selectable inputs
- Balanced high gain outputs
- Output peak and signal indicator LEDs
- Low noise floor
- THAT Corp mic preamp
- Ethernet network connectivity
Introducing the Atlas Sound TSDBB22 TSD BlueBridge 2 Input / 2 Output DSP Audio Processor, a cutting-edge platform designed to enhance sound reinforcement and AV applications. This versatile DSP processor combines audio and Ethernet connectivity, allowing for seamless integration with TCP/IP third-party control and programmability.
With microphone preamps sourced from THAT Corporation and 24-bit converters, the TSD BlueBridge processor achieves an impressive low noise floor, ensuring pristine audio quality. The 40-bit floating-point DSP engine is specifically designed to prevent digital clipping and deliver exceptional speed and processing power for handling complex algorithms in advanced system designs.
The unit is compatible with any network, and upon connection, it is instantly recognized and controllable. The TSD BlueBridge processors offer both fixed application embedded designs and the flexibility to create custom drag-and-drop systems, providing tailored solutions for a variety of audio setups.
Whether your system requires limited I/Os or demands a modern DSP platform, the TSD processor is the perfect choice. It can function as a standalone device to run a sound system or seamlessly integrate with existing setups to supplement their capabilities.
Experience the power and flexibility of the TSD BlueBridge 2 Input / 2 Output DSP Audio Processor. With its advanced features, superior audio processing capabilities, and user-friendly design, it is the ideal solution for elevating sound systems in various applications. Unlock the true potential of your audio setup with the TSD BlueBridge processor.
