Product Summary

















































Dimensions L x W x D: 1.8 x 19.0 x 9.0" (4.4 x 48.2 x 22.9 cm)
Input Type Microphone or Line, Software Selectable
Input Gain -40 to +15 dB in 0.25 dB Steps
Phantom Power 48 V, Software Enabled
Output Type Line
Output Gain -40 to +15 dB in 0.25 dB steps
Output Impedance 50 ohms
Processor 40-bit Floating Point
Sampling Rate 48 kHz
Power Requirements 90 - 240 VAC (50-60 Hz)
Digital to Analog Converter High Performance 24-bit






  • Open architecture programmability









  • THAT Corp microphone preamps









  • Ethernet network connectivity









  • TCP/IP third party control capability









  • Low noise floor









  • Four logic inputs/outputs









  • 48 kHz, 40-bit floating DSP engine









  • EQ modules include parametric, graphic, and anti-feedback





Introducing the Atlas Sound BB88 BlueBridge 8 Input / 8 Output DSP Audio Processor, a cutting-edge platform designed specifically for sound reinforcement and AV applications. This powerful DSP processor offers a range of advanced features and capabilities to enhance audio performance in various environments.

With its audio and Ethernet connectivity, the BlueBridge DSP Audio Processor allows for seamless integration with TCP/IP third-party control systems, enabling flexible control and programmability. The processor utilizes high-quality microphone preamps from THAT Corporation and 24-bit converters to achieve a low noise floor, ensuring pristine audio quality.

Equipped with a 40-bit floating point DSP engine, the processor effectively prevents digital clipping while delivering maximum processing speed and power for handling complex system designs and advanced algorithms. It operates flawlessly on any network, and upon connection, the processor is instantly recognized and controllable.

The BlueBridge DSP Audio Processor offers a comprehensive set of processing capabilities, including standard mixers, gain sharing auto-mixers, delays, equalizers, level controls, duckers, filters, and more. These features enable precise audio control and optimization, allowing users to tailor the sound to their specific requirements.

Designed with versatility in mind, this UL-rated processor is ideal for a wide range of applications, such as houses of worship, restaurants, presentation and conference rooms, courtrooms, and any other spaces that demand superior sound reinforcement and AV performance.

Experience the power and flexibility of the BlueBridge 8 Input / 8 Output DSP Audio Processor and elevate your audio system to new heights. With its advanced features, seamless connectivity, and exceptional audio processing capabilities, this processor is the perfect solution for achieving outstanding sound quality in diverse applications.

Atlas Sound BB88 BlueBridge 8 Input / 8 Output DSP Audio Processor

SKU: BB88 | UPC: 612079189397
Authorized Dealer Authorized Atlas Sound Dealer
Manufacturer Warranty Authorized dealer coverage
Expert Support Pre- and post-sale assistance

$3,804.99

BACK 2 SCHOOL SALE | additional discount in cart
Request a Quote
Atlas Sound BB88 BlueBridge 8 Input / 8 Output DSP Audio Processor $3,804.99
In Stock Current availability for this model
Free Ground Shipping On qualifying orders to the lower 48 states
Project & Volume Pricing Special pricing available for larger orders
Education & Government Purchase Orders Accepted for qualified organizations
Financing Available with Shop Pay
Special Pricing Available Education • Government • Nonprofits • Corporate • Volume Orders
✓ Tax-Exempt Purchasing Available

Key Features
