Blackmagic Design OpenGear SDI Distribution Converter CONVOPENGSDIDA
Blackmagic Design OpenGear SDI Distribution Converter CONVOPENGSDIDA is backordered and will ship as soon as it is back in stock.
- Manufacturer Warranty Included
- Lifetime Technical Support from OfficeWonderland
- No Sales Tax for Qualified Tax-Exempt Organizations
- Purchase Orders Accepted (Net 30 Available)
Blackmagic Design OpenGear SDI Distribution Converter CONVOPENGSDIDA
Key Features
- \n Rack Mount Card SDI Converter\n 1 Input/9 Outputs / SD/HD/2K/3G Support\n 16 Channels of Embedded Audio\n Sits on 2 Slots of 20-Slot 2RU Frames\n
Purchase Orders & Tax-Exempt
We proudly support schools, universities, government agencies, and qualified businesses.
- Net 30 Purchase Orders
- Tax-Exempt Sales for Eligible Organizations
- W-9 Available Upon Request
- Rack Mount Card SDI Converter
- 1 Input/9 Outputs / SD/HD/2K/3G Support
- 16 Channels of Embedded Audio
- Sits on 2 Slots of 20-Slot 2RU Frames
- OpenGear-compatible rack mount card SDI converter.
- Supports one SDI input and automatically distributes up to 9 SD/HD/2K/3G-SDI outputs.
- Inputs and outputs 16 channels of embedded audio.
- Sits on 2 slots of 20-slot 2RU frames and is hot-swappable.
- Can work in the same rack as converters made by different manufacturers.
- Re-clocks distribution to output at full 300' SDI capacity.
- Accepts ASI format and supports ancillary data.
The Blackmagic Design OpenGear SDI Distribution Converter is a converter in the form of a rack mount card that's compatible with the 20-slot 2RU OpenGear racks. It sits on two slots and can share the rack with converters made by different manufacturers. It is hot-swappable and so can be pulled out of the rack at any moment without the prerequisite of the rack first being powered off.
The SDI distribution converter, referred to also as an SDI DA, with "DA" short for "distribution amplifier", takes one SDI input and automatically distributes up to 9 SDI outputs, with up to 3Gbps supported on both the in and outs. The converter inputs and outputs video and 16 channels of embedded audio.
The converter features re-clocking distribution, re-clocking the incoming signal so the output can run at the full 300' that SDI has capacity for. The cables required are 75 ohm SDI cables, which are not included.
Aside from traditional data formats, the SDI DA accepts the ASI format and can thus transfer compressed, and it also accepts ancillary data such as timecode, closed captioning, and other data that's outside of the visible raster.
-
