Product Summary

Elo Touch 2002L E125897 19.5" Full HD Touchscreen Monitor

The Elo Touch 2002L E125897 is a 19.5-inch commercial touchscreen monitor designed for retail, hospitality, healthcare, point-of-sale, self-service kiosks, and interactive signage. This standless model features TouchPro® Projected Capacitive (PCAP) technology with 10-point multi-touch, delivering a smooth, tablet-like experience through its sleek edge-to-edge glass design. Compatible with Elo Edge Connect™ accessories, the 2002L provides the flexibility, durability, and performance required for demanding commercial environments.

Brilliant Full HD Display

Enjoy vibrant, crystal-clear visuals for interactive applications.

  • 19.5-inch LED-backlit TFT LCD
  • 1920 × 1080 Full HD resolution
  • 250-nit brightness (225 nits with touch)
  • 3000:1 contrast ratio
  • 178° wide viewing angles
  • Anti-glare glass surface

The Full HD display delivers sharp text and vivid colors while the anti-glare finish minimizes reflections in brightly lit commercial environments.

TouchPro® PCAP Technology

Responsive multi-touch performance.

  • Projected Capacitive (PCAP) touchscreen
  • Supports up to 10 simultaneous touch points
  • Edge-to-edge zero-bezel glass
  • USB touch interface
  • Fast, accurate touch response

TouchPro® technology provides precise, drift-free touch performance with the familiar feel of a tablet for intuitive interaction.

Elo Edge Connect™ Expandability

Customize the monitor for your business.

  • Magnetic stripe reader (MSR)
  • Fingerprint scanner
  • Barcode scanner
  • RFID reader
  • Webcam
  • Speaker bar
  • Status light
  • EMV payment cradle support

The Elo Edge Connect™ ecosystem allows optional peripherals to attach directly to the display, creating a clean, integrated solution for retail, hospitality, and self-service applications.

Standless Commercial Design

Optimized for custom installations.

  • Standless configuration (E125897)
  • Edge-to-edge glass design
  • 75 × 75 mm and 100 × 100 mm VESA mounting
  • Wall, pole, kiosk, or shelf mounting
  • Compact commercial footprint

The standless design offers maximum flexibility for OEMs, system integrators, and custom kiosk deployments.

Flexible Connectivity

Easy integration with commercial systems.

  • HDMI input
  • VGA input
  • USB Type-B touch interface
  • 3.5 mm audio input
  • Dual integrated 2W speakers

Comprehensive connectivity ensures compatibility with POS terminals, commercial PCs, media players, and embedded systems.

Commercial-Grade Reliability

Built for continuous business operation.

  • Commercial-grade construction
  • Anti-glare surface
  • Designed for continuous public use
  • Energy-efficient LED backlight
  • 3-year manufacturer's warranty

Engineered for demanding commercial environments, the 2002L delivers dependable long-term performance with minimal maintenance.

Elo Touch 2002L Full HD 20" Touchscreen Monitor E125897

SKU: E125897 | UPC: 843173124087
Authorized Dealer Authorized Elo Dealer
Manufacturer Warranty Authorized dealer coverage
Expert Support Pre- and post-sale assistance

$555.00

BACK 2 SCHOOL SALE | additional discount in cart
Request a Quote
Elo Touch 2002L Full HD 20" Touchscreen Monitor E125897 $555.00
In Stock Current availability for this model
Free Ground Shipping On qualifying orders to the lower 48 states
Project & Volume Pricing Special pricing available for larger orders
Education & Government Purchase Orders Accepted for qualified organizations
Financing Available with Shop Pay
Special Pricing Available Education • Government • Nonprofits • Corporate • Volume Orders
✓ Tax-Exempt Purchasing Available

Key Features

  • 20-Inch Full HD Touchscreen
  • Bright 250-Nit Commercial Display
  • 10-Point TouchPro PCAP Touch
  • Standless Flexible VESA Mounting
  • Expandable Edge Connect Accessories
  • Built-In Stereo Speaker Audio

Best For

  • 🛍️ Retail / Digital Signage
  • 🏨 Hospitality

Technical Details

Specifications

Screen Size
20"
Native Resolution
1920 x 1080 (Full HD)
Brightness
225 nits with touch panel; 250 nits for the LCD panel alone
Contrast Ratio
3000:01:00
Display Orientation
Landscape
Response Time
20 ms
Viewing Angle
Hor 178°, Ver 178°
Inputs
• Video inputs: 1x HDMI 1x Mini-VGA (cable to standard VGA included) Touchscreen input: 1x USB-B port for touchscreen communication with a computer Audio input: 1x 3.5mm analog audio jack
Outputs
• Audio output: None (audio is routed to the monitor's internal speakers)
Sound Output
2W x 2
WiFi
No
Communication Port
near-field communication (NFC/RFID) adapter
VESA Pattern
75 x 75 mm and 100 x 100 mm
