Elo Touch 2494L E146641 23.8" Open-Frame Touchscreen Monitor

The Elo Touch 2494L E146641 is a 23.8-inch commercial open-frame touchscreen monitor designed for OEMs, kiosk manufacturers, and system integrators. Featuring TouchPro® Projected Capacitive (PCAP) technology with 10-point multi-touch, a Full HD display, and a slim zero-bezel open-frame design, the 2494L delivers a responsive, tablet-like user experience. Built for retail, healthcare, gaming, industrial automation, transportation, and self-service applications, this commercial-grade monitor offers flexible installation options and dependable 24/7 performance.

Brilliant Full HD Display

Deliver sharp, vibrant visuals for interactive applications.

  • 23.8-inch LED-backlit TFT LCD
  • 1920 × 1080 Full HD resolution
  • 225-nit brightness (with PCAP touch)
  • 3000:1 contrast ratio
  • 178° ultra-wide viewing angles
  • 16:9 widescreen aspect ratio

The Full HD display produces crisp text, vivid colors, and wide viewing angles for an exceptional customer experience.

TouchPro® PCAP Technology

Responsive multi-touch built for commercial environments.

  • Projected Capacitive (PCAP) touchscreen
  • Supports up to 10 simultaneous touch points
  • USB 2.0 touch interface
  • Zero-bezel edge-to-edge glass
  • Touch-through capability
  • Tablet-like touch experience

TouchPro® technology delivers fast, accurate interaction and supports touch-through mode for installations behind protective glass.

Slim Open-Frame Design

Purpose-built for seamless integration.

  • Zero-bezel open-frame construction
  • Flush-mount brackets included
  • 200 × 100 mm VESA mounting
  • Landscape or portrait installation
  • Remote OSD control box included

The slim industrial design simplifies integration into kiosks, cabinets, gaming machines, and custom enclosures.

Flexible Connectivity

Integrates easily with commercial systems.

  • HDMI input
  • DisplayPort input
  • VGA input
  • USB Type-B touch interface
  • RJ45 port for remote OSD
  • External 12V DC power

Multiple video and touch interfaces ensure compatibility with both modern and legacy commercial hardware.

Commercial-Grade Reliability

Designed for continuous operation.

  • Commercial-grade construction
  • 50,000-hour MTBF
  • IK07 impact-resistant front glass
  • UL 60950 ball-drop compliant
  • Energy-efficient LED backlight
  • 3-year manufacturer's warranty

Built to withstand demanding public environments, the 2494L provides dependable long-term performance with minimal maintenance.

Elo Touch 2494L Full HD 23.8" Full HD Open Frame Touchscreen Monitor E146641

SKU: E146641 | UPC: 843173100029
Authorized Dealer Authorized Elo Dealer
Manufacturer Warranty Authorized dealer coverage
Expert Support Pre- and post-sale assistance

$799.00

BACK 2 SCHOOL SALE | additional discount in cart
Request a Quote
Elo Touch 2494L Full HD 23.8" Full HD Open Frame Touchscreen Monitor E146641 $799.00
In Stock Current availability for this model
Free Ground Shipping On qualifying orders to the lower 48 states
Project & Volume Pricing Special pricing available for larger orders
Education & Government Purchase Orders Accepted for qualified organizations
Financing Available with Shop Pay
Special Pricing Available Education • Government • Nonprofits • Corporate • Volume Orders
✓ Tax-Exempt Purchasing Available

Key Features

  • 24-Inch Full HD Open-Frame
  • Bright 225-Nit Touch Display
  • Reliable 24/7 Operation
  • Portrait And Landscape Support
  • 10-Point TouchPro PCAP Touch
  • Touch-Through Glass Capability

Best For

  • 🛍️ Retail / Digital Signage
  • 🏨 Hospitality

Technical Details

Specifications

Screen Size
23.8"
Native Resolution
1920 x 1080 (Full HD)
Brightness
225 nits typical (250 nits for the LCD panel alone)
Contrast Ratio
3000:01:00
Display Orientation
Landscape
Refresh Rate
60 hz
Response Time
16ms
Viewing Angle
Hor 178°, Ver 178°
Inputs
• Video: HDMI 1.3 (Type A) DisplayPort 1.1a VGA (Female DB-15) Touch: USB 2.0 (Type B) On-Screen Display (OSD): RJ45 for a tethered remote control Power: 12VDC power input
WiFi
No
VESA Pattern
200 x 100 mm
