Built in Precision ND Filters

URSA Mini Pro features high quality ND filters that let you quickly reduce the amount of light entering the camera. Designed to match the colorimetry and color science of the camera, the 2, 4 and 6 stop filters provide you with additional latitude even under harsh lighting. The IR filters have been designed to filter both optical wavelengths and IR wavelengths evenly to eliminate IR contamination of the images from which many ND filters can suffer. URSA Mini Pro ND filters are true optical filters with a precision mechanism that quickly moves them into place when the ND filter dial is turned. Filter settings can even be displayed as either an ND number, stop reduction or fraction on the LCD!

---

USB-C for Direct Recording to External Disks

Blackmagic URSA Mini Pro features an innovative high speed USB-C Expansion Port. The 4.6K G2 model features USB‑C 3.1 Gen 1 which operates at up to 5 Gb/s, while the new 12K model has a USB‑C 3.1 Gen 2 for a blistering 10 Gb/s. You can connect and power external flash disks and SSDs or on URSA Mini Pro 12K you can connect the new URSA Mini Recorder for recording to fast NVMe SSD drives for longer recording times. NVMe SSD drives are ideal for shooting 12K in the highest constant quality 12‑bit Blackmagic RAW in the Q0 setting or for high frame rates. When shooting is complete you can simply move the external disk to your computer and start editing from the same disk, eliminating file copying!

High Resolution Monitoring and Camera Control

The built in 4 inch fold out touchscreen on URSA Mini Pro is a bright, high resolution color display with a wide viewing angle that makes it perfect for monitoring and reviewing shots on set! The screen can also show you a "heads up display" overlay with critical information such as format, frame rate, iris, timecode, shutter angle, white balance, ISO and more. Plus you get a histogram, card recording status indicators and audio meters! You can show or hide the heads up display by simply swiping up or down. The fold out touchscreen also lets you use the incredible Blackmagic operating software so you get super fast access to every camera function, digital slate for metadata management and more!

Full Size, Durable Connections that Work with Standard Cables

URSA Mini Pro features multiple connections such as 12G‑SDI out, LANC, balanced XLR audio with 48 volt phantom power, timecode in, reference input and a headphone connection. There’s also a 4 pin XLR DC output for powering accessories such as a viewfinder, and an HD‑SDI output for monitoring.That means you can connect an SDI display for on set monitoring of images, with or without overlays that show critical information and camera status. There is also a 12 pin Hi‑rose connector for controlling servo zoom lenses. URSA Mini Pro 4.6K G2 and URSA Mini Pro 12K both include a USB‑C expansion port for recording to external disks, which on the 12K model is conveniently located on the rear of the camera.

Wireless Bluetooth Camera Control

If you're positioning the camera on the end of a jib or gimbal, you can get full control via Bluetooth from up to 30 feet away. You can download the Blackmagic Camera Control app for your iPad or use third party apps such as Bluetooth+ or trigger on your iOS and Android devices. There’s even a free developer SDK with sample code available from the Blackmagic Design developer website, so you can create your own remote camera control and digital slate solutions! Imagine building an app that can jam sync timecode and trigger all cameras to record at the same time. The possibilities are endless!

Optional Shoulder Mount Kit

URSA Mini Pro cameras include multiple ¼ inch mount points on the bottom so you can attach them directly to any tripod. When you need to quickly move from tripod to handheld and back, you can use the optional Blackmagic URSA Mini Shoulder Kit. This kit includes the shoulder pad with built in rosettes, rail mounts and integrated quick lock release attachment points for instantly latching onto the quick release plate without removing the shoulder pad. You also get a top handle for carrying the camera and attaching accessories such as the Blackmagic URSA Viewfinder, a support arm for Blackmagic Video Assist and more!

High Resolution Viewfinder for Accurate Focus

The optional Blackmagic URSA Viewfinder is designed to be the perfect match for URSA Mini Pro. You get a high resolution 1920 x 1080 color OLED display with precision glass optics, adjustable diopter and built in digital focus chart so you get perfect focus every time. As well as a clean feed of the image you can also view critical status information such as frame guides and more. You can easily access the fully assignable function buttons on top of the viewfinder for zooming, turning on overlays, focus peaking control and more. To preserve OLED screen life, there’s a built in sensor so the OLED only turns on when you’re looking through the viewfinder. There’s even a built in tally light!

Blackmagic URSA Mini Recorder

The new Blackmagic URSA Mini Recorder lets you record 12‑bit Blackmagic RAW files onto fast 2.5 inch SSDs, including the latest U.2 NVMe Enterprise SSDs. SSDs such as the latest 7mm U.2 NVMe disks are super fast, delivering data transfer speeds of up to 900 MB/s! This blazing fast performance allows you longer recording times for full resolution 4K, 8K and 12K 12‑bit Blackmagic RAW files in the highest quality Q0 encoding. The unique design of the Blackmagic URSA Mini Recorder means it attaches directly to the back of your URSA Mini Pro between the camera and the battery. It’s controlled via the USB‑C so you don’t have to worry about manually starting or stopping the SSD recorder.

Compatible with Industry Standard Batteries and Power

URSA Mini Pro includes a 4‑pin XLR industry standard power connector that works with 12V to 18V external power supplies. That means it’s easy to use the camera with all of your existing power supplies and batteries! URSA Mini Pro cameras use the same battery power connector and mounting points on the rear of the camera so you can use a wide range of battery plates from manufacturers such as IDX, Blueshape, Anton Bauer and more. You can also add the optional Blackmagic URSA VLock Battery Plate or Blackmagic URSA Gold Battery Plate for using popular V‑Mount and Gold Mount batteries.
