General
RM-WDR: SPECIFICATIONS
Dimensions
Wireless Microphone
Colour
Black
Dimensions (W x D x H)
W 89.0 mm x D 89.0 mm x H 26.0 mm (including rubber feet)
Weight
130 g
Directivity
Unidirectional (Sensitivity: 120°)
Frequency Response
160 Hz - 16 kHz
Sensitivity
-15.4 dBFS/Pa
Power
Rechargable Li-ion Battery 3.6 V 2350 mA/h. For Charge I/F: USB Type C, RM-WCH Charger I/F (4pin)
Maximum Power Consumption
5.0 V 0.7 A
Battery
Talk Time: 20 hours / Standby Time: 7 days / Charge Time: Full charging: 5 hours (80% charging: 3 hours)
In Operation
Temperature: 0°C - 40°C / Humidity: 20% - 85% (no condensation)
In Charging
Temperature: 5°C - 40°C / Humidity: 20% - 85% (no condensation)
Storage
Temperature: -20°C - 60°C / Humidity: 10% - 90% (no condensation)
Indicators
Mic (3 colours) x 1, Battery (3 colours) x 1
Buttons
Mic x 1, Battery x 1, Pair x 1
I/O
USB TypeC (for battery charging) x 1, Charger I/F (4pin) x 1
Accessories
Battery (RM-WBT) x 1, Owner’s Manual x 1
Options
Replacement Battery RM-WBT
RM-WOM: SPECIFICATIONS
Description
Wireless Microphone
Colour
Black
Dimensions (W x D x H)
W 89.0 mm x D 89.0 mm x H 26.0 mm (including rubber feet)
Weight
126 g
Directivity
Omnidirectional (Sensitivity: 360°)
Frequency Response
160 Hz - 16 kHz
Sensitivity
-14 dBFS/Pa
Power
Rechargable Li-ion Battery 3.6 V 2350 mA/h. For Charge I/F: USB Type C, RM-WCH Charger I/F (4pin)
Maximum Power Consumption
5.0 V 0.7 A
Battery
Talk Time: 20 hours / Standby Time: 7 days / Charge Time: Full charging: 5 hours (80% charging: 3 hours)
In Operation
Temperature: 0°C - 40°C / Humidity: 20% - 85% (no condensation)
In Charging
Temperature: 5°C - 40°C / Humidity: 20% - 85% (no condensation)
Storage
Temperature: -20°C - 60°C / Humidity: 10% - 90% (no condensation)
Indicators
Mic (3 colours) x 1, Battery (3 colours) x 1
Buttons
Mic x 4, Battery x 1, Pair x 1
I/O
USB TypeC (for battery charging) x 1, Charger I/F (4pin) x 1
Accessories
Battery (RM-WBT) x 1, Owner’s Manual x 1
Options
Replacement Battery RM-WBT
RM-WGL: SPECIFICATIONS
Description
Wireless Microphone
Colour
Black
Dimensions (W x D x H)
W 89.0 mm x D 89.0 mm x 308.4 mm (including rubber feet and to center of gooseneck mic)
Weight
152 g (including battery)
Directivity
Unidirectional (Sensitivity: 90°)
Frequency Response
160 Hz - 16 kHz
Sensitivity
-20.0 dBFS/Pa
Power
Rechargable Li-ion Battery 3.6 V 2350 mA/h. For Charge I/F: USB Type C, RM-WCH Charger I/F (4pin)
Maximum Power Consumption
5.0 V 0.7 A
Battery
Talk Time: 20 hours / Standby Time: 7 days / Charge Time: Full charging: 5 hours (80% charging: 3 hours)
In Operation
Temperature: 0°C - 40°C / Humidity: 20% - 85% (no condensation)
In Charging
Temperature: 5°C - 40°C / Humidity: 20% - 85% (no condensation)
Storage
Temperature: -20°C - 60°C / Humidity: 10% - 90% (no condensation)
Indicators
Mic (3 colours) x 1, Ring (3 colours) x 1, Battery (3 colours) x 1
Buttons
Mic x 1, Battery x 1, Pair x 1
I/O
USB TypeC (for battery charging) x 1, Charger I/F (4pin) x 1
Accessories
Battery (RM-WBT) x 1, Owner’s Manual x 1
Options
Replacement Battery RM-WBT
RM-WGS: SPECIFICATIONS
Description
Wireless Microphone
Colour
Black
Dimensions (W x D x H)
W 89.0 mm x D 89.0 mm x H 171.2 mm (including rubber feet and to center of gooseneck mic)
Weight
140 g
Directivity
Unidirectional (Sensitivity: 90°)
Frequency Response
160 Hz - 16 kHz
Sensitivity
-20.0 dBFS/Pa
Power
Rechargable Li-ion Battery 3.6 V 2350 mA/h. For Charge I/F: USB Type C, RM-WCH Charger I/F (4pin)
Maximum Power Consumption
5.0 V 0.7 A
Battery
Talk Time: 20 hours / Standby Time: 7 days / Charge Time: Full charging: 5 hours (80% charging: 3 hours)
In Operation
Temperature: 0°C - 40°C / Humidity: 20% - 85% (no condensation)
In Charging
Temperature: 5°C - 40°C / Humidity: 20% - 85% (no condensation)
Storage
Temperature: -20°C - 60°C / Humidity: 10% - 90% (no condensation)
Indicators
Mic (3 colours) x 1, Ring (3 colours) x 1, Battery (3 colours) x 1
Buttons
Mic x 1, Battery x 1, Pair x 1
I/O
USB TypeC (for battery charging) x 1, Charger I/F (4pin) x 1
Accessories
Battery (RM-WBT) x 1, Owner’s Manual x 1
Options
Replacement Battery RM-WBT
RM-WAP-8: SPECIFICATIONS
Description
Microphone Accesspoint
Colour
White (paintable surface)
Dimensions (W x D x H)
W 171.2 mm x D 172.5 mm x H 42.8 mm
Weight
650 g (including mouting bracket)
Power Requirement
IEEE 802.3af (PoE Class 3)
Maximum Power Consumption
48 V 0.2 A
In Operation
Temperature: 0°C - 40°C / Humidity: 20% - 85% (no condensation)
Storage
Temperature: -20°C - 60°C / Humidity: 10% - 90% (no condensation)
Indicators
Power (3 colours) x 1, Status (3 colours) x 1
Buttons
Reset x 1
Connector
RJ-45 (Dante Audio, Dante Control, Remote Control, PoE)
Audio I/O
Dante (1 in / 8 out)
Mount
Wall mount, Ceiling mount (with blacket), Flat placing
Max Device Number with RM-CR
Max Device Number – 2 units
Accessories
Owner’s Manual x 1, Mounting bracket x 1 *Screw for Mounting Bracket or Safety Wire are not included
RM-WCH-8: SPECIFICATIONS
Description
Microphone Charger
Colour
Black
Dimensions (W x D x H)
W 304 mm x D 188 mm x H 41.5 mm (including rubber feet)
Weight
800 g
Material
Plastic
Power
DC IN (16 V, 2.4 A)
Maximum Power Consumption
16.0 V 2.0 A
In Operation
Temperature: 0°C - 40°C / Humidity: 20% - 85% (no condensation)
In Charging
Temperature: 5°C - 40°C / Humidity: 20% - 85% (no condensation)
Storage
Temperature: -20°C - 60°C / Humidity: 10% - 90% (no condensation)
Indicators
Activate (3 colours) x 1
Buttons
Activate x 1, Pair x 1
I/O
DC IN x 1
Accessories
Owner’s Manual x 1, AC adapter x 1, Cable x 1 (for Japan and USA), x 3 (for Europe)
RM-WBT: SPECIFICATIONS
Description
Replacement Battery
Colour
Black
Dimensions (W x D x H)
H 11.15 mm x W 34.95 mm x D 52.5 mm
Weight
42 g
Voltage
3.6 V
Nominal Capacity
2350 mA/h
Maximum Charge Current
1.59 A
Maximum Charge Voltage
4.20 V
Maximum Discharge Current
2.30 A
In Operation
Temperature: 0°C - 40°C / Humidity: 20% - 85% (no condensation)
Storage
Temperature: -20°C - 60°C / Humidity: 10% - 90% (no condensation)
Accessories
RM-WBT Safety Brochure x 1
RM-WAP-8: NETWORK SPECIFICATIONS
Ethernet
Dante Audio/Dante Control, Remote Control, Web UI, PoE
Cable Requirements
CAT5e or higher (STP)
AUDIO SPECIFICATIONS
Frequency Response
160 Hz - 16 kHz
Sampling Rate
48 kHz
Bit Depth
24 bit
Latency
30 ms nominal (w/o signal processing in High Quality mode)
Audio I/O Dante
1 in x 8/16 out
Maximum Input Level of SPL
RM-WDR: 109.4 dB SPL / RM-WOM:108.0 dB SPL / RM-WGL:114.0 dB SPL / RM-WGS:114.0 dB SPL
Self Noise
RM-WDR: 33.3 dBA SPL / RM-WOM: 25.8 dBA SPL / RM-WGL: 36.4 dBA SPL / RM-WGS:36.4 dBA SPL
SNR (Ref. 94 dB SPL at 1 kHz)
RM-WDR: 60.7 dBA / RM-WOM: 68.2 dBA / RM-WGL: 57.6 dBA / RM-WGS: 57.6 dBA
Sensitivity
RM-WDR:-15.4 dBFS/Pa / RM-WOM:-14.0 dBFS/Pa / RM-WGL:-20.0 dBFS/Pa / RM-WGS: -20.0 dBFS/Pa
Dynamic Range
RM-WDR:76.1 dBA / RM-WOM:82.2 dBA / RM-WGL:77.6 dBA / RM-WGS:77.6 dBA
Signal Processing
AEC, Noise Reduction, De-reverbration, AGC, PEQ, Output Gain Adjustment
WIRELESS SPECIFICATIONS
Radio Method
1.9 GHz DECT standard
Radio Frequency Range
USA, Canada: 1920.0 MHz - 1930.0 MHz / Japan: 1893.5 MHz - 1906.1 MHz / EU, Australia, New Zealand, Norway, UK: 1880.0 MHz - 1900.0 MHz
Maximum RF Power Level (EIRP)
USA, Canada: 20.1 dBm Japan: 27.0 dBm EU, Australia, New Zealand, Norway, Sweden, Finland, Denmark, UK: 25.9 dBm
Maximum Coverage Distance
50 m (depends on the usage environment)
Encryption
AES (256-bit
