Product Summary
























































Ethernet I/F 10/100 Mbps
Protocol SIP RFC 3261 Compatible
Power Input PoE 802.3af or 48VDC
Payload Types G711
Operating Temperature Range -30° to 55° C (-22° to 131° F)
Regulatory Compliance FCC Class A, UL 60950
Output Signal Amplitudes 2.0 VPP Maximum
Width 6.2" (154.48mm)
Height 1.22" (30.99mm)
Output Level +2dBm Nominal
Total Harmonic Distortion 0.5% Maximum
Depth 4.5" (114.3mm)
Weight 1.6 lbs. (0.73kg)


  • Four Paging Zones

  • Fifteen Paging Zone Groups

  • PoE 802.3af Enabled

  • SIP RFC 3261 Compatible

  • Compatible with IP/PBX Servers

  • Delayed Paging

  • Web-Based Configuration


Introducing the Atlas Sound IP-to-Analog Four Zone PoE Gateway (for SIP applications) IPS-ZC4 - the perfect solution for extending communication beyond the network. These gateways are designed to create analog overhead paging systems in environments where SIP servers or VoIP communications managers may not support paging, or where third-party notification applications are not required.

With the AtlasIED IPS-ZC4 gateways, you can easily register them as SIP devices directly to a SIP server or VoIP communications manager. They offer up to 15 paging groups and feature 4-zone outputs, allowing for flexible paging configurations. When a caller dials a paging number, the IPS-ZC4 establishes a one-way voice path to its designated analog outputs, enabling seamless paging functionality.

One notable integration is within a Cisco Environment, where the IPS-ZC4 gateways can join Cisco's Unified Survivable Remote Site Telephony (SRST) as supported devices within the SRST endpoint architecture. Cisco's SRST provides call-processing redundancy for remote locations in case of a WAN outage, ensuring uninterrupted communication. During emergencies, when WAN connectivity might be compromised, the ability to extend LAN communication between phones and speakers with visual notifications becomes crucial.

The versatility of the IPS-ZC4 gateways makes them suitable for various applications. Whether it's corporate environments, education institutions, entertainment complexes, industrial facilities, government buildings, healthcare facilities, houses of worship, or transportation hubs, these gateways can fulfill the need for critical alerts and public address systems. They provide a unified and reliable communications platform, ideal for organizations seeking an enterprise-class solution.

Choose the AtlasIED IPS-ZC4 SIP-to-Analog 4-endpoint zone gateways to enhance your communication infrastructure and ensure effective and efficient messaging in any critical situation.

Atlas Sound IP-to-Analog Four Zone PoE Gateway (for SIP applications) IPS-ZC4

SKU: IPS\ZC4
Authorized Dealer Authorized Atlas Sound Dealer
Manufacturer Warranty Authorized dealer coverage
Expert Support Pre- and post-sale assistance

$880.99

BACK 2 SCHOOL SALE | additional discount in cart
Request a Quote
Atlas Sound IP-to-Analog Four Zone PoE Gateway (for SIP applications) IPS-ZC4 $880.99
In Stock Current availability for this model
Free Ground Shipping On qualifying orders to the lower 48 states
Project & Volume Pricing Special pricing available for larger orders
Education & Government Purchase Orders Accepted for qualified organizations
Financing Available with Shop Pay
Special Pricing Available Education • Government • Nonprofits • Corporate • Volume Orders
✓ Tax-Exempt Purchasing Available

Key Features

  • <table>\n<tbody>\n<tr>\n<td>Ethernet I/F</td>\n<td>10/100 Mbps</td>\n</tr>\n<tr>\n<td>Protocol</td>\n<td>SIP RFC 3261 Compatible</td>\n</tr>\n<tr>\n<td>Power Input</td>\n<td>PoE 802.3af or 48VDC</td>\n</tr>\n<tr>\n<td>Payload Types</td>\n<td>G711</td>\n</tr>\n<tr>\n<td>Operating Temperature Range</td>\n<td>-30° to 55° C (-22° to 131° F)</td>\n</tr>\n<tr>\n<td>Regulatory Compliance</td>\n<td>FCC Class A, UL 60950</td>\n</tr>\n<tr>\n<td>Output Signal Amplitudes</td>\n<td>2.0 VPP Maximum</td>\n</tr>\n<tr>\n<td>Width</td>\n<td>6.2" (154.48mm)</td>\n</tr>\n<tr>\n<td>Height</td>\n<td>1.22" (30.99mm)</td>\n</tr>\n<tr>\n<td>Output Level</td>\n<td>+2dBm Nominal</td>\n</tr>\n<tr>\n<td>Total Harmonic Distortion</td>\n<td>0.5% Maximum</td>\n</tr>\n<tr>\n<td>Depth</td>\n<td>4.5" (114.3mm)</td>\n</tr>\n<tr>\n<td>Weight</td>\n<td>1.6 lbs. (0.73kg)</td>\n</tr>\n</tbody>\n</table>
